BC847BS – PHILIPS
PHILIPS D/C 0034 AND 0309
Stock Quantity: 4558
Selling Unit: Each
| Quantity | Price (ex VAT) |
|---|---|
| 1+ | 2.92 |
| 10+ | |
| 50+ | |
| 100+ |
4558 in stock
Contact us for volume pricing
- Same day shipping if ordered before 14.00 GMT
- 6 month warranty on all stock items
- All stock held and shipped from our UK warehouse
- Worldwide shipping available, contact us for a quotation
- We can ship on your DHL or UPS account if required
- Any import duties or taxes are the responsibility of the receiver
Overview
The Nexperia BC847BS is a dual NPN bipolar junction transistor (BJT) designed for general-purpose amplification and switching applications. Its critical operational characteristic lies in its complementary nature when paired with PNP transistors, enabling efficient push-pull configurations. A key design consideration for this device is managing thermal dissipation; while rated for 300 mW, exceeding this in high-frequency switching can lead to premature junction degradation, a common trade-off in compact SMT packages like the TSSOP-6.
Key Features
- NPN Silicon Bipolar Junction Transistor (BJT)
- Dual transistor configuration in a single package
- Maximum DC Collector Current (Ic): 100 mA
- Collector-Emitter Voltage (VCEO): 45 V
- Power Dissipation (Pd): 300 mW
- Dimensions: 2.2 mm (L) x 1.35 mm (W) x 1 mm (H)
Applications
The component is engineered for deployment in systems requiring high reliability and performance under specific operating conditions. It provides functional stability across the stated design envelope.
- Low-power audio amplification stages
- General-purpose signal switching in control circuits
- Complementary output stages in Class AB amplifiers
- Driving small indicator LEDs or relays
