SN74LVC540ADW – TEXAS INSTRUMENTS

Overview

The SN74LVC540ADW is an octal buffer and line driver integrated circuit manufactured by TEXAS INSTRUMENTS. This device provides eight independent channels of non-inverting buffering with tri-state outputs, enabling isolation of sections within a digital system. It is supplied in a SOIC-20 package.

Key Features

• Octal buffer configuration
• Non-inverting logic
• Tri-state outputs for bus isolation
• Wide operating voltage range
• SOIC-20 package

Applications

This octal buffer is commonly used to increase drive capability in digital circuits and to isolate sections of a system. The tri-state outputs allow multiple devices to share a common bus.

• Memory address buffering
• Data bus isolation
• Logic level translation
