SN74LVC125ADG4 – TEXAS INSTRUMENTS

Part Number:

SN74LVC125ADG4

Manufacturer:

TEXAS INSTRUMENTS

Date Code:

RoHS:

RoHS Compliant

MSL:

COO:

MALAYSIA

Description:

Four-Channel Non-Inverting CMOS Buffer/Line Driver, 14‑Pin SOIC Package

Datasheet:

Spotted a problem with product information? – let us know

ORDER NOW

Stock Quantity: 190

Selling Unit: Each

Quantity	Price (ex VAT)
1+	11.41
10+
50+
100+

190 in stock

Contact us for volume pricing

Same day shipping if ordered before 14.00 GMT
6 month warranty on all stock items
All stock held and shipped from our UK warehouse
Worldwide shipping available, contact us for a quotation
We can ship on your DHL or UPS account if required
Any import duties or taxes are the responsibility of the receiver

Product Details:

Overview

The SN74LVC125ADG4 is a quad buffer/line driver from TEXAS INSTRUMENTS. This device features four independent non-inverting channels designed for 2-V to 5.5-V VCC operation. It is supplied in a 14-pin SOIC (Small Outline Integrated Circuit) package and provides improved propagation delay times compared to standard logic buffers.

Key Features

Quadruple buffer configuration
Non-inverting output
2-V to 5.5-V VCC operation
Low power consumption
14-Pin SOIC Package

Applications

This buffer/line driver is commonly used in systems requiring signal buffering or amplification. Its wide operating voltage range makes it suitable for various digital logic applications. The SOIC package allows for efficient board space utilization.

Memory addressing
Data bus isolation
Clock line driving
