SN74HCT14DRG4 – TEXAS INSTRUMENTS
6‑Channel Inverter with Schmitt-Trigger Inputs, 4.5 V to 5.5 V, 14‑SOIC, -40 to 85 °C
Stock Quantity: 2175
Selling Unit: Each
| Quantity | Price (ex VAT) |
|---|---|
| 1+ | 3.51 |
| 10+ | |
| 50+ | |
| 100+ |
2175 in stock
Contact us for volume pricing
- Same day shipping if ordered before 14.00 GMT
- 6 month warranty on all stock items
- All stock held and shipped from our UK warehouse
- Worldwide shipping available, contact us for a quotation
- We can ship on your DHL or UPS account if required
- Any import duties or taxes are the responsibility of the receiver
Overview
The SN74HCT14DRG4 is a Hex Schmitt-Trigger Inverter manufactured by TEXAS INSTRUMENTS. This device features six independent inverter channels, each with Schmitt-trigger inputs to improve noise immunity and signal conditioning. It operates within a supply voltage range of 4.5 V to 5.5 V and is provided in a 14-pin SOIC (Small Outline Integrated Circuit) package. The operating temperature range is specified from -40°C to +85°C.
Key Features
- Schmitt-Trigger Inputs
- Six Independent Inverters
- 4.5 V to 5.5 V Operating Voltage
- 14-Pin SOIC Package
Applications
This hex inverter is commonly used in digital logic circuits where signal conditioning and noise reduction are required. Its Schmitt-trigger inputs make it suitable for applications with slow or noisy input signals. The device’s operating temperature range allows for deployment in various industrial and commercial settings.
- Wave Shaping Circuits
- Logic Level Conversion
- Debouncing Switches
