SN74HC138D – TEXAS INSTRUMENTS
Part Number:
SN74HC138D
Manufacturer:
Date Code:
RoHS:
RoHS Compliant
MSL:
1
COO:
MEXICO
Description:
3-Line to 8-Line Decoder/Demultiplexer, 5 V, 25 mA
Datasheet:
Spotted a problem with product information? – let us know
ORDER NOW
Stock Quantity: 611
Selling Unit: Each
| Quantity | Price (ex VAT) |
|---|---|
| 1+ | 0.45 |
| 10+ | |
| 50+ | |
| 100+ |
611 in stock
Contact us for volume pricing
- Same day shipping if ordered before 14.00 GMT
- 6 month warranty on all stock items
- All stock held and shipped from our UK warehouse
- Worldwide shipping available, contact us for a quotation
- We can ship on your DHL or UPS account if required
- Any import duties or taxes are the responsibility of the receiver
Product Details:
Overview
The SN74HC138D is a 3-line to 8-line decoder/demultiplexer manufactured by Texas Instruments. This device accepts three binary address inputs and activates one of eight output lines based on the input code. It operates at 5V and can source or sink up to 25mA of current. The SN74HC138D is supplied in a SOIC-16 package.
Key Features
- 3-Line to 8-Line Decoding
- Low Power Consumption
- 5V Operating Voltage
- 25mA Output Drive Capability
Applications
This decoder/demultiplexer is commonly used in digital systems for address decoding, memory selection, and data routing. Its ability to select one of eight outputs makes it suitable for various control and interface applications.
- Memory Address Decoding
- Data Routing
- Logic Multiplexing
