RP73PF1J261RBTDF – TE CONNECTIVITY
5-2176087-6, Resistor, 0603, 261Ω, 0.1%, 25PPM
Stock Quantity: 1000
Selling Unit: Each
| Quantity | Price (ex VAT) |
|---|---|
| 1+ | 0.15 |
| 10+ | |
| 50+ | |
| 100+ |
1000 in stock
Contact us for volume pricing
- Same day shipping if ordered before 14.00 GMT
- 6 month warranty on all stock items
- All stock held and shipped from our UK warehouse
- Worldwide shipping available, contact us for a quotation
- We can ship on your DHL or UPS account if required
- Any import duties or taxes are the responsibility of the receiver
Overview
The TE Connectivity RP73PF1J261RBTDF is a high-precision, 0.1% tolerance thin-film surface-mount resistor designed for demanding electronic circuits. Its critical operational characteristic lies in its exceptionally low temperature coefficient of 25 PPM/°C, ensuring stable resistance values across a wide operating range of -55°C to +155°C, vital for consistent performance in thermally dynamic environments. A key design consideration when utilizing such high-precision components is managing parasitic inductance and capacitance, which can affect signal integrity at higher frequencies, necessitating careful PCB layout and component placement to achieve optimal performance.
Key Features
- Resistance: 261 Ohms
- Tolerance: 0.1%
- Temperature Coefficient: 25 PPM/°C
- Power Rating: 100 mW (1/10 W)
- Maximum Operating Temperature: +155°C
- Dimensions: 1.60mm x 0.80mm x 0.45mm (0603/1608 package)
Applications
The component is engineered for deployment in systems requiring high reliability and performance under specific operating conditions. It provides functional stability across the stated design envelope.
- Precision voltage division in analog signal conditioning circuits
- Current sensing in power management units
- Reference voltage generation for data converters
- Calibration networks in test and measurement equipment
