RP73PF2A34RBTDF – TE CONNECTIVITY
34 Ω, 0805 Resistor, 0.1%, 25 PPM
Stock Quantity: 0
Contact us for volume pricing
- Same day shipping if ordered before 14.00 GMT
- 6 month warranty on all stock items
- All stock held and shipped from our UK warehouse
- Worldwide shipping available, contact us for a quotation
- We can ship on your DHL or UPS account if required
- Any import duties or taxes are the responsibility of the receiver
Overview
The TE Connectivity RP73PF2A34RBTDF is a high-precision, surface-mount thin-film resistor engineered for demanding circuit applications. Its defining characteristic is the exceptional 0.1% tolerance and a tight 25 PPM/°C temperature coefficient, ensuring stable resistance values across a broad operating range of -55°C to +155°C. A critical design consideration for such precision components is the trade-off between power dissipation and thermal management; while rated at 250mW, designers must account for potential self-heating effects in high-density, high-power applications to maintain parametric integrity.
Key Features
- Resistance: 34 Ohms
- Tolerance: 0.1%
- Temperature Coefficient: 25 PPM/°C
- Power Rating: 250 mW (1/4 W)
- Voltage Rating: 150 V
- Dimensions: 2.0 mm x 1.25 mm x 0.55 mm (0805/2012 package)
Applications
The component is engineered for deployment in systems requiring high reliability and performance under specific operating conditions. It provides functional stability across the stated design envelope.
- Precision voltage dividers in analog signal conditioning circuits
- Current sensing in high-efficiency power management units
- Reference voltage generation for ADCs and DACs
- Gain setting in low-noise operational amplifier configurations
