CS8406-CSZ – CIRRUS
Audio Transmitter, 2-Channel, 28-SOIC Package.
Stock Quantity: 64
Selling Unit: Each
| Quantity | Price (ex VAT) |
|---|---|
| 1+ | 11.24 |
| 10+ | |
| 50+ | |
| 100+ |
64 in stock
Contact us for volume pricing
- Same day shipping if ordered before 14.00 GMT
- 6 month warranty on all stock items
- All stock held and shipped from our UK warehouse
- Worldwide shipping available, contact us for a quotation
- We can ship on your DHL or UPS account if required
- Any import duties or taxes are the responsibility of the receiver
Overview
The Cirrus Logic CS8406-CSZ is a high-performance digital audio transmitter designed to interface with a variety of audio sources and digital audio receivers. Its primary function is to reliably transmit uncompressed digital audio streams, supporting resolutions up to 384 bits, crucial for maintaining signal integrity in professional audio applications. A key design consideration is managing the trade-off between its flexible I2C/SPI control interfaces and the potential for EMI generation at higher clock speeds, necessitating careful PCB layout and shielding in sensitive environments.
Key Features
- Digital Audio Transmitter, 1 Channel
- Supports up to 384-bit Resolution
- I2C and SPI Interface Compatibility
- Wide Supply Voltage Range: 3.3V to 5V
- Low Operating Current: 12.7 mA
- SOIC-28 Package (Dimensions: 17.9mm x 7.5mm x 1.75mm)
Applications
The component is engineered for deployment in systems requiring high reliability and performance under specific operating conditions. It provides functional stability across the stated design envelope.
- Digital audio signal routing in AV receivers
- High-fidelity audio playback systems
- Professional audio interfaces and mixers
- Digital signal transmission in broadcast equipment
