ADL5511ACPZ-R7 – ANALOG DEVICES

Part Number:

ADL5511ACPZ-R7

Manufacturer:

ANALOG DEVICES

Date Code:

RoHS:

RoHS Compliant

MSL:

COO:

SOUTH KOREA

Description:

6 GHz TruPwr RMS Envelope Detector, LFCSP

Datasheet:

Spotted a problem with product information? – let us know

ORDER NOW

Stock Quantity: 0

GET QUOTE

Contact us for volume pricing

Same day shipping if ordered before 14.00 GMT
6 month warranty on all stock items
All stock held and shipped from our UK warehouse
Worldwide shipping available, contact us for a quotation
We can ship on your DHL or UPS account if required
Any import duties or taxes are the responsibility of the receiver

Product Details:

Overview

The ADL5511ACPZ-R7 is a 6 GHz RMS envelope detector manufactured by Analog Devices. This device accurately measures the true power of RF signals. It is supplied in a LFCSP (Lead Frame Chip Scale Package) for space-constrained applications, providing a compact solution for power monitoring.

Key Features

Frequency Range: Up to 6 GHz
True RMS Power Measurement
LFCSP Package
Low Power Consumption

Applications

This RMS envelope detector is commonly used in various radio frequency systems requiring precise power monitoring and control. Its wide bandwidth and accurate measurement capabilities make it suitable for diverse application environments.

Power Amplifier Control Loops
Transmitter Power Monitoring
RF Signal Strength Indication (RSSI)
