A6S-8104-H – OMRON

Part Number:

A6S-8104-H

Manufacturer:

OMRON

Date Code:

RoHS:

RoHS Compliant

MSL:

Not Applicable

COO:

VIETNAM

Description:

SPST 8-Position DIP Switch, 25mA 24VDC, Slide Actuator, Surface Mount

Datasheet:

Spotted a problem with product information? – let us know

ORDER NOW

Stock Quantity: 0

GET QUOTE

Contact us for volume pricing

Same day shipping if ordered before 14.00 GMT
6 month warranty on all stock items
All stock held and shipped from our UK warehouse
Worldwide shipping available, contact us for a quotation
We can ship on your DHL or UPS account if required
Any import duties or taxes are the responsibility of the receiver

Product Details:

Overview

The A6S-8104-H is an 8-position Single-Pole Single-Throw (SPST) DIP switch manufactured by OMRON. This component provides a means of configuring electronic circuits through manual selection. It features a slide actuator and is designed for surface mount assembly on printed circuit boards. Its electrical specifications include a rating of 25mA at 24VDC.

Key Features

8 Independent Switch Positions
SPST Circuit Configuration
Surface Mount Termination
Slide Actuator Type
24VDC Switching Voltage

Applications

This DIP switch is commonly used in various electronic systems where manual configuration or selection of different operating modes is required. It is suitable for use in environments where infrequent changes to circuit parameters are needed.

Address and Mode Selection
Logic Level Configuration
Calibration Settings
