74HCT165D – PHILIPS
8-Bit Shift Register, Single Element, 16-SO
Stock Quantity: 1
Selling Unit: Each
| Quantity | Price (ex VAT) |
|---|---|
| 1+ | 2.92 |
| 10+ | |
| 50+ | |
| 100+ |
1 in stock
Contact us for volume pricing
- Same day shipping if ordered before 14.00 GMT
- 6 month warranty on all stock items
- All stock held and shipped from our UK warehouse
- Worldwide shipping available, contact us for a quotation
- We can ship on your DHL or UPS account if required
- Any import duties or taxes are the responsibility of the receiver
Overview
The Nexperia 74HCT165D,653 is a high-speed 8-bit parallel-in/serial-out shift register designed for efficient data acquisition and serial transmission. Its critical operational characteristic is the ability to accept up to eight bits of parallel data simultaneously and output them sequentially, making it ideal for multiplexing inputs. A key design consideration when integrating this device is managing the clock edge synchronization; while its TTL-compatible inputs offer flexibility, ensuring clean clock signals is paramount to prevent metastable states and data corruption, especially in noisy environments.
Key Features
- 8-bit parallel-to-serial conversion
- Complementary Q and /Q outputs
- 4.5V to 5.5V supply voltage range
- Maximum clock frequency of 40 MHz
- 16-SOIC (0.154″, 3.90mm Width) surface mount package
- -40°C to 125°C operating temperature range
Applications
The component is engineered for deployment in systems requiring high reliability and performance under specific operating conditions. It provides functional stability across the stated design envelope.
- Serializing sensor data for microcontrollers
- Input expansion for digital control systems
- Data buffering in communication interfaces
- Implementing simple serial data acquisition modules
