PT65- 101 – HARTMANN

Part Number:

PT65- 101

Manufacturer:

HARTMANN

Date Code:

RoHS:

RoHS Compliant

MSL:

COO:

Description:

Rotary Coded Switch, 10-Position, 24VDC, BCD, 400mA, Through Hole

Datasheet:

Spotted a problem with product information? – let us know

ORDER NOW

Stock Quantity: 0

GET QUOTE

Contact us for volume pricing

Same day shipping if ordered before 14.00 GMT
6 month warranty on all stock items
All stock held and shipped from our UK warehouse
Worldwide shipping available, contact us for a quotation
We can ship on your DHL or UPS account if required
Any import duties or taxes are the responsibility of the receiver

Product Details:

Overview

The HARTMANN PT65-101 is a 10-position rotary coded switch designed for selecting one of ten discrete positions. This through-hole component provides a Binary Coded Decimal (BCD) output at 24VDC with a maximum current of 400mA. It is suitable for various control and selection applications requiring a defined digital output based on the rotary position.

Key Features

10-Position Rotary Selection
BCD Output Code
24VDC Operating Voltage
400mA Maximum Current
Through-Hole Mounting

Applications

This rotary coded switch is commonly used in applications where a user-selectable digital input is required. Its BCD output simplifies interfacing with digital logic circuits and microcontrollers for position encoding.

Industrial Control Panels
Instrumentation Equipment
Test and Measurement Devices
Embedded Systems
