MM74HCT05M – FSC

Part Number:

MM74HCT05M

Manufacturer:

FSC

Date Code:

RoHS:

RoHS Compliant

MSL:

COO:

Description:

CMOS Hex Inverter (Open Drain), 74HC Series, 4.5–5.5 V, SOIC‑14 Package

Datasheet:

Spotted a problem with product information? – let us know

ORDER NOW

Stock Quantity: 39

Selling Unit: Each

Quantity	Price (ex VAT)
1+	0.9
10+
50+
100+

39 in stock

Contact us for volume pricing

Same day shipping if ordered before 14.00 GMT
6 month warranty on all stock items
All stock held and shipped from our UK warehouse
Worldwide shipping available, contact us for a quotation
We can ship on your DHL or UPS account if required
Any import duties or taxes are the responsibility of the receiver

Product Details:

Overview

The MM74HCT05M is a CMOS hex inverter manufactured by FSC. This device features six independent inverter gates with open-drain outputs. Operating within a supply voltage range of 4.5V to 5.5V, it belongs to the 74HC series logic family. The component is supplied in a standard SOIC-14 package.

Key Features

CMOS Logic Technology
Hex Inverter Configuration
Open-Drain Outputs
4.5V to 5.5V Operating Voltage

Applications

This hex inverter is commonly used in digital systems requiring signal inversion and level shifting. The open-drain outputs allow for wired-OR configurations and interfacing with different voltage levels. It finds use in various electronic circuits and embedded systems.

Logic Level Conversion
Signal Inversion
Wired-OR Logic Implementation
