M74HC4066M1R – STMicroelectronics

Part Number:

M74HC4066M1R

Manufacturer:

STMicroelectronics

Date Code:

RoHS:

MSL:

COO:

Description:

Quad Bilateral Switch, 5 V Logic, HCF4xxx, M74HC/HCT, 74AC/ACT, 74VHC/VHCT

Datasheet:

Spotted a problem with product information? – let us know

ORDER NOW

Stock Quantity: 187

Selling Unit: Each

Quantity	Price (ex VAT)
1+	0.55
10+
50+
100+

187 in stock

Contact us for volume pricing

Same day shipping if ordered before 14.00 GMT
6 month warranty on all stock items
All stock held and shipped from our UK warehouse
Worldwide shipping available, contact us for a quotation
We can ship on your DHL or UPS account if required
Any import duties or taxes are the responsibility of the receiver

Product Details:

Overview

The M74HC4066M1R is a quad bilateral switch manufactured by STMicroelectronics. This device provides four independent single-pole, single-throw (SPST) analog switches. It is designed for 5V logic systems and is part of the HCF4xxx family, compatible with M74HC/HCT, 74AC/ACT, and 74VHC/VHCT logic series. The component is supplied in a surface-mount package.

Key Features

Quad SPST configuration
5V operating voltage
HCF4xxx family compatibility
Low ON resistance
High OFF isolation

Applications

This quad bilateral switch is commonly used in analog signal routing, signal multiplexing, and sample-and-hold circuits. Its compatibility with various logic families makes it suitable for diverse electronic systems requiring signal control.

Analog signal switching
Data acquisition systems
Audio signal routing
Multiplexing applications
