HSMC-A431-X90M1 – AVAGO
LED, Red, 626nm, 2.2V, 4-PLCC, Discrete Indicator, 30mcd
Stock Quantity: 1556
Selling Unit: Each
| Quantity | Price (ex VAT) |
|---|---|
| 1+ | 0.26 |
| 10+ | |
| 50+ | |
| 100+ |
1556 in stock
Contact us for volume pricing
- Same day shipping if ordered before 14.00 GMT
- 6 month warranty on all stock items
- All stock held and shipped from our UK warehouse
- Worldwide shipping available, contact us for a quotation
- We can ship on your DHL or UPS account if required
- Any import duties or taxes are the responsibility of the receiver
Overview
The Broadcom HSMC-A431-X90M1 is a high-brightness red LED designed for discrete indication applications, emitting light at a dominant wavelength of 626nm with a typical forward voltage of 2.2V. Its 4-PLCC surface-mount package offers robust mechanical stability for automated assembly processes. A critical design consideration for this component is managing thermal dissipation; while its 4000mcd luminous intensity is impressive, sustained operation at higher drive currents can lead to junction temperature increases, potentially impacting long-term reliability and spectral purity. Therefore, careful PCB layout and heatsinking strategies are paramount to achieving optimal performance and lifespan in demanding environments.
Key Features
- Dominant Wavelength: 626nm
- Forward Voltage (Typ): 2.2V
- Luminous Intensity: 4000mcd
- Viewing Angle: 30°
- Package: 4-PLCC (3.20mm L x 2.80mm W x 3.87mm H)
- Colorless Clear Lens
Applications
The component is engineered for deployment in systems requiring high reliability and performance under specific operating conditions. It provides functional stability across the stated design envelope.
- Status indication in industrial control panels
- Front-panel indicators for consumer electronics
- Illumination for optical sensors in automated equipment
- Visual feedback in medical device interfaces
