GRM2165C1H220GZ01D – MURATA
22 pF, 50 V Ceramic Capacitor, C0G/NP0 Dielectric, 0805 Package
Stock Quantity: 2682
Selling Unit: Each
| Quantity | Price (ex VAT) |
|---|---|
| 1+ | 0.49 |
| 10+ | |
| 50+ | |
| 100+ |
2682 in stock
Contact us for volume pricing
- Same day shipping if ordered before 14.00 GMT
- 6 month warranty on all stock items
- All stock held and shipped from our UK warehouse
- Worldwide shipping available, contact us for a quotation
- We can ship on your DHL or UPS account if required
- Any import duties or taxes are the responsibility of the receiver
Overview
The Murata GRM2165C1H220GZ01D is a high-precision 22 pF ceramic capacitor designed for demanding electronic circuits. Its critical operational characteristic lies in its C0G/NP0 dielectric, which offers exceptional temperature stability and low dielectric loss, ensuring consistent capacitance values across a wide operating range from -55°C to 125°C. A key design consideration for engineers is balancing this superior stability with the inherent brittleness of multilayer ceramic capacitors (MLCCs) under mechanical stress, necessitating careful PCB layout and assembly processes to prevent micro-cracking and ensure long-term reliability.
Key Features
- Capacitance: 22 pF
- Tolerance: ±2%
- Rated Voltage: 50V
- Temperature Coefficient: C0G, NP0
- Operating Temperature: -55°C to 125°C
- Package: 0805 (2012 Metric), 0.079″ L x 0.049″ W (2.00mm x 1.25mm)
Applications
The component is engineered for deployment in systems requiring high reliability and performance under specific operating conditions. It provides functional stability across the stated design envelope.
- High-frequency signal coupling in RF front-ends
- Precision filtering in analog signal processing chains
- Tuning elements in resonant circuits
- Decoupling for sensitive high-speed digital logic ICs
