ES02MSABE – C&K
Slide Switch, SPST, Surface Mount, Right Angle termination.
Stock Quantity: 53
Selling Unit: Each
| Quantity | Price (ex VAT) |
|---|---|
| 1+ | 7 |
| 10+ | |
| 50+ | |
| 100+ |
53 in stock
Contact us for volume pricing
- Same day shipping if ordered before 14.00 GMT
- 6 month warranty on all stock items
- All stock held and shipped from our UK warehouse
- Worldwide shipping available, contact us for a quotation
- We can ship on your DHL or UPS account if required
- Any import duties or taxes are the responsibility of the receiver
Overview
The C&K ES02MSABE is a robust Single Pole Single Throw (SPST) slide switch designed for reliable on-off control in compact electronic assemblies. Its key operational characteristic lies in its low contact resistance and gold-plated bronze contacts, ensuring consistent signal integrity even with its modest 0.4VA/20V rating. A critical design consideration for engineers is managing the trade-off between its IP57 sealing, which enhances environmental protection, and the potential for increased actuation force or reduced mechanical travel compared to unsealed counterparts, necessitating careful consideration in user interface design and automated assembly processes.
Key Features
- SPST Circuit Configuration
- 0.4VA (AC/DC) Current Rating at 20V
- Surface Mount, Right Angle Mounting Type
- Gull Wing Termination Style
- Epoxy Sealed Terminals & IP57 Rating
- Dimensions: 3.07mm Actuator Length, 2.29mm Switch Travel
Applications
The component is engineered for deployment in systems requiring high reliability and performance under specific operating conditions. It provides functional stability across the stated design envelope.
- Power control for portable instrumentation
- Signal routing in compact IoT devices
- On-off switching for battery-powered modules
- User interface elements in ruggedized equipment
