ELC16B101L – PANASONIC

Part Number:

ELC16B101L

Manufacturer:

PANASONIC

Date Code:

UNKNOWN

RoHS:

RoHS Compliant

MSL:

COO:

INDONESIA

Description:

Inductor, 100µH ±10%, 2.6A Idc, 72mΩ Rdc, Ferrite, Leaded

Datasheet:

Spotted a problem with product information? – let us know

ORDER NOW

Stock Quantity: 0

GET QUOTE

Contact us for volume pricing

Same day shipping if ordered before 14.00 GMT
6 month warranty on all stock items
All stock held and shipped from our UK warehouse
Worldwide shipping available, contact us for a quotation
We can ship on your DHL or UPS account if required
Any import duties or taxes are the responsibility of the receiver

Product Details:

Overview

The ELC16B101L is a leaded inductor manufactured by PANASONIC. This component provides a nominal inductance of 100µH with a tolerance of ±10%. It is characterized by a maximum DC resistance (Rdc) of 72mΩ and a saturation current (Idc) rating of 2.6A. The core material is ferrite, providing stable performance in various circuit designs.

Key Features

100µH Inductance ±10%
2.6A DC Current Rating
72mΩ DC Resistance (Max)
Ferrite Core Material

Applications

This inductor is suitable for use in power supply filtering, DC-DC conversion, and general signal conditioning circuits. Its leaded construction facilitates easy prototyping and integration into through-hole PCB designs. The component’s current handling capability makes it applicable in moderate power applications.

DC-DC Converters
Power Supply Filtering
Signal Conditioning
