ELC10D560E – PANASONIC

Part Number:

ELC10D560E

Manufacturer:

PANASONIC

Date Code:

RoHS:

RoHS Compliant

MSL:

COO:

INDONESIA

Description:

Inductor, 56µH, 2.3A, 67mΩ, Unshielded, Radial, Wirewound

Datasheet:

Spotted a problem with product information? – let us know

ORDER NOW

Stock Quantity: 0

GET QUOTE

Contact us for volume pricing

Same day shipping if ordered before 14.00 GMT
6 month warranty on all stock items
All stock held and shipped from our UK warehouse
Worldwide shipping available, contact us for a quotation
We can ship on your DHL or UPS account if required
Any import duties or taxes are the responsibility of the receiver

Product Details:

Overview

The ELC10D560E is a 56µH radial leaded inductor manufactured by Panasonic. This wirewound inductor is designed for power supply and filtering applications requiring a current rating of up to 2.3A. It features an unshielded construction and a low DC resistance of 67mΩ, contributing to energy efficiency in circuit designs.

Key Features

Inductance: 56 µH
Rated Current: 2.3 A
DC Resistance: 67 mΩ
Package Type: Radial
Construction: Wirewound, Unshielded

Applications

This inductor is suitable for various electronic circuits where inductance is needed for filtering, energy storage, or impedance matching. Its radial form factor allows for easy integration into through-hole PCB designs.

DC-DC Converters
Power Supply Filtering
Noise Suppression
General Purpose Inductance
