EECS0HD104H – PANASONIC
5.5 V, 100 mF Supercapacitor, EDLC, Axial-Can, Horizontal Mount
Stock Quantity: 311
Selling Unit: Each
| Quantity | Price (ex VAT) |
|---|---|
| 1+ | 2.02 |
| 10+ | |
| 50+ | |
| 100+ |
311 in stock
Contact us for volume pricing
- Same day shipping if ordered before 14.00 GMT
- 6 month warranty on all stock items
- All stock held and shipped from our UK warehouse
- Worldwide shipping available, contact us for a quotation
- We can ship on your DHL or UPS account if required
- Any import duties or taxes are the responsibility of the receiver
Overview
The Panasonic EEC-S0HD104H is a 100 mF Electric Double-Layer Capacitor (EDLC) designed for high-energy density storage applications, offering a robust 5.5V operational voltage. Its primary function is to provide rapid charge and discharge cycles, acting as a power buffer or backup power source. A critical design consideration for EDLCs like the EEC-S0HD104H is the significant capacitance tolerance (-20% to +80%); engineers must account for this wide variation during system design to ensure consistent performance across all units, particularly in applications sensitive to voltage drop characteristics.
Key Features
- Capacitance: 100 mF
- Rated Voltage: 5.5 V
- Equivalent Series Resistance (ESR): 75Ω @ 1kHz
- Operating Temperature: -25°C to 70°C
- Lifetime: 1000 Hrs @ 70°C
- Dimensions: 10.50mm Diameter, 5.50mm Height
Applications
The component is engineered for deployment in systems requiring high reliability and performance under specific operating conditions. It provides functional stability across the stated design envelope.
- Short-term power backup for volatile memory (e.g., SRAM, microcontrollers)
- Peak power assist for pulsed loads in portable electronics
- Energy harvesting system smoothing and buffering
- Automotive electronic system voltage stabilization
