ECEV0JA102P – PANASONIC
1000µF 6.3V Radial Aluminum Electrolytic Capacitor, SMD, 2000 Hrs @ 85°C
Stock Quantity: 180
Selling Unit: Each
| Quantity | Price (ex VAT) |
|---|---|
| 1+ | 2.92 |
| 10+ | |
| 50+ | |
| 100+ |
180 in stock
Contact us for volume pricing
- Same day shipping if ordered before 14.00 GMT
- 6 month warranty on all stock items
- All stock held and shipped from our UK warehouse
- Worldwide shipping available, contact us for a quotation
- We can ship on your DHL or UPS account if required
- Any import duties or taxes are the responsibility of the receiver
Overview
The Panasonic ECE-V0JA102P is a 1000 µF, 6.3V aluminum electrolytic capacitor designed for surface-mount applications, offering essential bulk capacitance for power filtering and energy storage. Its key operational characteristic is its ability to handle significant ripple current (700 mA @ 120 Hz), crucial for smoothing rectified DC voltages. A critical design consideration for this component, typical of many electrolytic types, is the trade-off between volumetric efficiency and Equivalent Series Resistance (ESR); while providing substantial capacitance in a compact form factor, its ESR is not explicitly specified as ultra-low, necessitating careful selection in high-frequency switching applications where ESR can significantly impact efficiency and thermal performance.
Key Features
- Capacitance: 1000 µF
- Voltage Rating: 6.3 VDC
- Tolerance: ±20%
- Ripple Current: 700 mA @ 120 Hz
- Operating Temperature: -40°C to 85°C
- Dimensions: 10.00mm Diameter x 10.20mm Height
Applications
The component is engineered for deployment in systems requiring high reliability and performance under specific operating conditions. It provides functional stability across the stated design envelope.
- Bulk capacitance for DC-DC converter output filtering
- Power supply decoupling in low-voltage consumer electronics
- Smoothing rectified AC in portable device charging circuits
- Energy reservoir for transient load demands in IoT devices
