DV-16230-S1FBLY – DATA VISION
2×16 LCD Backlight Display
Stock Quantity: 0
Contact us for volume pricing
- Same day shipping if ordered before 14.00 GMT
- 6 month warranty on all stock items
- All stock held and shipped from our UK warehouse
- Worldwide shipping available, contact us for a quotation
- We can ship on your DHL or UPS account if required
- Any import duties or taxes are the responsibility of the receiver
The DATA VISION DV-16230-S1FBLY is a 2×16 character LCD module incorporating an integrated LED backlight. The module utilizes a chip-on-board (COB) construction, directly mounting the LCD controller and driver IC onto the PCB to minimize physical dimensions. It is designed for applications requiring a compact alphanumeric display with enhanced visibility under varying ambient lighting conditions. The LED backlight is typically driven by a current-limiting resistor network to maintain consistent luminance and extend operational lifespan. The interface is likely a standard parallel interface (e.g., 4-bit or 8-bit) compatible with common microcontrollers, and requires a single 5V supply for both logic and backlight operation. Character generation is handled by the onboard controller, supporting ASCII characters and potentially custom glyphs. The module’s operating temperature range and viewing angle characteristics should be verified against the manufacturer’s datasheet for specific application suitability.
