CPF0805B10R7E1 – TE CONNECTIVITY
2-1614890-9, Thin Film Resistor, 0805, 10.7Ω, 0.1%, 25PPM
Stock Quantity: 0
Contact us for volume pricing
- Same day shipping if ordered before 14.00 GMT
- 6 month warranty on all stock items
- All stock held and shipped from our UK warehouse
- Worldwide shipping available, contact us for a quotation
- We can ship on your DHL or UPS account if required
- Any import duties or taxes are the responsibility of the receiver
Overview
The TE CONNECTIVITY CPF0805B10R7E1 is a precision thin-film surface-mount chip resistor designed for applications demanding stringent tolerance and stability. Its primary function is to provide a highly accurate and stable resistance value of 10.7 Ohms with a tight ±0.1% tolerance, crucial for maintaining signal integrity in sensitive circuits. A key design consideration for thin-film resistors like the CPF0805B10R7E1 is their susceptibility to parasitic inductance at higher frequencies; while offering excellent DC precision, engineers must carefully evaluate their suitability for very high-speed digital or RF signal paths where parasitic effects can become dominant, potentially necessitating alternative component technologies or careful layout techniques.
Key Features
- Resistance: 10.7 Ohms
- Tolerance: ±0.1%
- Power Rating: 0.1W (1/10W)
- Temperature Coefficient: ±25ppm/°C
- Operating Temperature Range: -55°C to +155°C
- Package: 0805 (2.00mm x 1.25mm x 0.65mm)
Applications
The component is engineered for deployment in systems requiring high reliability and performance under specific operating conditions. It provides functional stability across the stated design envelope.
- Precision voltage division in analog signal conditioning circuits
- Current sensing in low-power, high-accuracy measurement systems
- Reference resistor for DAC/ADC input stages
- Impedance matching in low-frequency communication interfaces
