CD40106BCM – FSC
Inverter IC, 6-Channel, Schmitt Trigger, 14-SOIC.
Stock Quantity: 1
Selling Unit: Each
| Quantity | Price (ex VAT) |
|---|---|
| 1+ | 0.28 |
| 10+ | |
| 50+ | |
| 100+ |
1 in stock
Contact us for volume pricing
- Same day shipping if ordered before 14.00 GMT
- 6 month warranty on all stock items
- All stock held and shipped from our UK warehouse
- Worldwide shipping available, contact us for a quotation
- We can ship on your DHL or UPS account if required
- Any import duties or taxes are the responsibility of the receiver
Overview
The onsemi (Fairchild) CD40106BCM is a hex Schmitt trigger inverter IC, crucial for signal conditioning in noise-sensitive digital systems. Its primary function is to introduce hysteresis, effectively cleaning up slow or noisy input signals by providing distinct switching thresholds for rising and falling edges. A key design consideration when implementing the CD40106BCM is the trade-off between its robust noise immunity and its relatively slow propagation delays (up to 400 ns), which can limit its use in ultra-high-speed applications where timing margins are extremely tight.
Key Features
- Six independent Schmitt trigger inverters
- Wide operating supply voltage: 3V to 15V
- CMOS logic family with low power consumption
- Extended temperature range: -55°C to +125°C
- SOIC-14 surface-mount package (3.9mm x 8.7mm)
- Maximum output current: ±4.2 mA
Applications
The component is engineered for deployment in systems requiring high reliability and performance under specific operating conditions. It provides functional stability across the stated design envelope.
- Debouncing mechanical switches in control interfaces
- Creating stable clock signals from noisy oscillators
- Implementing pulse shaping for digital signal integrity
- Generating reliable trigger signals in industrial automation
