BTS7700G – INFINEON
9 A Brush DC Motor Controller IC, NMOS, PDSO28 Package
Stock Quantity: 6
Selling Unit: Each
| Quantity | Price (ex VAT) |
|---|---|
| 1+ | 6.66 |
| 10+ | |
| 50+ | |
| 100+ |
6 in stock
Contact us for volume pricing
- Same day shipping if ordered before 14.00 GMT
- 6 month warranty on all stock items
- All stock held and shipped from our UK warehouse
- Worldwide shipping available, contact us for a quotation
- We can ship on your DHL or UPS account if required
- Any import duties or taxes are the responsibility of the receiver
Overview
The Infineon BTS7700G is a high-side power switch designed for demanding automotive and industrial applications, offering precise current control and robust protection. Its key operational characteristic lies in its integrated current sense capability, enabling sophisticated feedback loops for load monitoring and fault detection. A critical design consideration for engineers is managing the trade-off between rapid fault response and potential nuisance tripping due to transient inrush currents, necessitating careful selection of external filtering components and trip thresholds to ensure system stability and component longevity.
Key Features
- SMD/SMT Mounting (DSO-28 package)
- Operating Temperature Range: -40°C to +150°C
- Integrated Current Sense Output
- Low Standby Current: 4 mA
- High-side Switching Topology
- Moisture Sensitive Device (MSL 1)
Applications
The component is engineered for deployment in systems requiring high reliability and performance under specific operating conditions. It provides functional stability across the stated design envelope.
- Automotive body control module (BCM) load switching
- Industrial motor drive current limiting
- LED array illumination control with overcurrent protection
- Power sequencing for sensitive electronic subsystems
