B6PS-VH – TBC
Header, 6-Position, 0.156″ (3.96mm) Pitch, Right Angle, Through-Hole
Stock Quantity: 4
Selling Unit: Each
| Quantity | Price (ex VAT) |
|---|---|
| 1+ | 0.31 |
| 10+ | |
| 50+ | |
| 100+ |
4 in stock
Contact us for volume pricing
- Same day shipping if ordered before 14.00 GMT
- 6 month warranty on all stock items
- All stock held and shipped from our UK warehouse
- Worldwide shipping available, contact us for a quotation
- We can ship on your DHL or UPS account if required
- Any import duties or taxes are the responsibility of the receiver
Overview
The JST Sales America Inc. B6PS-VH is a robust 6-position right-angle header connector designed for reliable board-to-wire interconnectivity. Its 3.96mm pitch and 10A current rating make it suitable for moderate power applications, but engineers must carefully consider the 250V voltage limit to prevent dielectric breakdown in higher-voltage systems. The shrouded design with a locking ramp ensures secure mating and prevents accidental disengagement, a critical factor in vibration-prone environments.
Key Features
- Connector Type: Header, Male Pin
- Pitch: 0.156″ (3.96mm)
- Positions: 6
- Mounting Type: Through Hole, Right Angle
- Current Rating: 10A
- Voltage Rating: 250V
- Dimensions: 8.51mm (Insulation Height)
Applications
The component is engineered for deployment in systems requiring high reliability and performance under specific operating conditions. It provides functional stability across the stated design envelope.
- Power supply unit internal wiring
- Industrial control panel signal distribution
- Automotive interior lighting harnesses
- Consumer appliance motor control interfaces
