804511 – BERGQUIST

Part Number:

804511

Manufacturer:

BERGQUIST

Date Code:

RoHS:

RoHS Compliant

MSL:

–

COO:

Description:

THERMALCLAD STAR IMS CREE XLAMP XP-G

Datasheet:

Spotted a problem with product information? – let us know

ORDER NOW

Stock Quantity: 0

GET QUOTE

Contact us for volume pricing

Same day shipping if ordered before 14.00 GMT
6 month warranty on all stock items
All stock held and shipped from our UK warehouse
Worldwide shipping available, contact us for a quotation
We can ship on your DHL or UPS account if required
Any import duties or taxes are the responsibility of the receiver

Product Details:

Overview

The 804511 is a THERMALCLAD insulated metal substrate (IMS) from BERGQUIST, specifically designed in a STAR configuration. This PCB provides efficient heat dissipation for high-power components, notably optimized for CREE XLAMP XP-G series LEDs. The THERMALCLAD material ensures effective thermal management in demanding applications.

Key Features

BERGQUIST THERMALCLAD material
STAR PCB configuration
Optimized for CREE XLAMP XP-G LEDs
Insulated Metal Substrate (IMS)

Applications

This BERGQUIST THERMALCLAD IMS is commonly used in scenarios requiring effective thermal transfer from power components to a heatsink. Its design makes it suitable for various lighting and power applications where thermal management is critical for component longevity and performance.

High-power LED lighting
Power amplifier modules
DC-DC converters
