3362P-1-502LF – BOURNS
5 kΩ, 0.5W, TH Cermet Trimmer Potentiometer, 1 Turn, Top Adjust, PC Pins
Stock Quantity: 329
Selling Unit: Each
| Quantity | Price (ex VAT) |
|---|---|
| 1+ | 0.67 |
| 10+ | |
| 50+ | |
| 100+ |
329 in stock
Contact us for volume pricing
- Same day shipping if ordered before 14.00 GMT
- 6 month warranty on all stock items
- All stock held and shipped from our UK warehouse
- Worldwide shipping available, contact us for a quotation
- We can ship on your DHL or UPS account if required
- Any import duties or taxes are the responsibility of the receiver
Overview
The Bourns 3362P-1-502LF is a 5 kΩ cermet trimmer potentiometer designed for precise resistance adjustment in electronic circuits. Its 0.5W power rating and ±10% tolerance are critical for applications demanding stable voltage division or gain control. A key design consideration is the trade-off between the cermet resistive element’s stability and its inherent parasitic capacitance, which can impact performance in high-frequency signal paths, necessitating careful layout and filtering in sensitive RF designs.
Key Features
- Resistance: 5 kOhms
- Power Rating: 0.5W (1/2W)
- Tolerance: ±10%
- Temperature Coefficient: ±100ppm/°C
- Adjustment: 1.0 Turn Top Adjustment
- Dimensions: 6.99mm x 6.60mm (0.275″ x 0.260″ Face)
Applications
The component is engineered for deployment in systems requiring high reliability and performance under specific operating conditions. It provides functional stability across the stated design envelope.
- Calibration of sensor signal conditioning circuits
- Setting bias points in analog amplifier stages
- Fine-tuning voltage references in power supply regulation
- Adjusting gain in audio processing modules
