3341-1S – 3M
D-Sub Connector Jackscrew Socket, Standard Size, Hardware
Stock Quantity: 10
Selling Unit: Each
| Quantity | Price (ex VAT) |
|---|---|
| 1+ | 2.31 |
| 10+ | |
| 50+ | |
| 100+ |
10 in stock
Contact us for volume pricing
- Same day shipping if ordered before 14.00 GMT
- 6 month warranty on all stock items
- All stock held and shipped from our UK warehouse
- Worldwide shipping available, contact us for a quotation
- We can ship on your DHL or UPS account if required
- Any import duties or taxes are the responsibility of the receiver
Overview
The 3M 3341-1S is a critical component for securing standard D-Sub connectors, providing a robust mechanical interface essential for preventing signal integrity degradation caused by vibration or accidental dislodging. Its primary function is to act as a receptacle for the jackscrew, ensuring a firm connection. A key design consideration is the trade-off between thread engagement length and overall connector profile; the 0.310″ length offers sufficient retention for most industrial applications without excessively increasing the connector’s footprint, a common challenge in miniaturized systems.
Key Features
- Accessory Type: Jackscrew Socket
- For Use With/Related Products: Standard D-Sub Connectors
- Length – Threaded Portion Below Head: 0.310″ (7.87mm)
- Thread Size: 4-40 Socket, 4-40 Screw
- Features: Hardware Included, Lock Washer
- Dimensions: Compact form factor suitable for standard D-Sub housings
Applications
The component is engineered for deployment in systems requiring high reliability and performance under specific operating conditions. It provides functional stability across the stated design envelope.
- Secure mating of data acquisition interfaces in industrial automation
- Preventing connector separation in ruggedized portable test equipment
- Ensuring stable communication links in telecommunications infrastructure
- Maintaining reliable signal path integrity in medical device interconnects
