293D225X9020B2TE3 – VISHAY
2.2µF Tantalum Capacitor; 20V; 3.5Ω; 1411 (3528 Metric) SMD
Stock Quantity: 719
Selling Unit: Each
| Quantity | Price (ex VAT) |
|---|---|
| 1+ | 0.29 |
| 10+ | |
| 50+ | |
| 100+ |
719 in stock
Contact us for volume pricing
- Same day shipping if ordered before 14.00 GMT
- 6 month warranty on all stock items
- All stock held and shipped from our UK warehouse
- Worldwide shipping available, contact us for a quotation
- We can ship on your DHL or UPS account if required
- Any import duties or taxes are the responsibility of the receiver
Overview
The Vishay Sprague 293D225X9020B2TE3 is a 2.2 µF molded tantalum capacitor designed for 20V applications, offering a ±10% capacitance tolerance and a low 3.5 Ohm Equivalent Series Resistance (ESR) at 100kHz. While its compact 1411 (3528 metric) package and surface-mount capability are ideal for space-constrained designs, engineers must carefully consider the ripple current handling capabilities relative to its ESR. Exceeding recommended ripple current can lead to premature failure due to self-heating, a critical trade-off in high-frequency power delivery circuits.
Key Features
- Capacitance: 2.2 µF
- Tolerance: ±10%
- Rated Voltage: 20 V
- Equivalent Series Resistance (ESR): 3.5 Ohm (at 100kHz)
- Operating Temperature: -55°C to 125°C
- Package: 1411 (3528 Metric), 3.50mm x 2.80mm x 2.11mm
Applications
The component is engineered for deployment in systems requiring high reliability and performance under specific operating conditions. It provides functional stability across the stated design envelope.
- Decoupling and filtering for low-power digital ICs
- Bulk capacitance in compact DC-DC converter input/output stages
- Smoothing for audio signal paths in portable electronics
- Transient voltage suppression in sensitive analog circuits
