292336-1 – TYCO ELECTRONICS
USB Type A Connector, USB 2.0, 4-Way, Right Angle, Through-Hole Mount
Stock Quantity: 147
Selling Unit: Each
| Quantity | Price (ex VAT) |
|---|---|
| 1+ | 1.77 |
| 10+ | |
| 50+ | |
| 100+ |
147 in stock
Contact us for volume pricing
- Same day shipping if ordered before 14.00 GMT
- 6 month warranty on all stock items
- All stock held and shipped from our UK warehouse
- Worldwide shipping available, contact us for a quotation
- We can ship on your DHL or UPS account if required
- Any import duties or taxes are the responsibility of the receiver
Overview
The TE Connectivity 292336-1 is a robust USB 2.0 Type-A receptacle connector designed for right-angle, through-hole mounting, providing a reliable interface for data and power transmission. Its shielded copper alloy construction ensures signal integrity by mitigating electromagnetic interference, a critical factor in high-speed digital systems. A key design consideration for engineers is balancing the 1A per contact current rating against thermal management in densely populated PCBs, as excessive current can lead to connector degradation and reduced mating cycle lifespan, even within its -55°C to 85°C operating range.
Key Features
- Connector Type: USB-A (USB TYPE-A)
- Interface Standard: USB 2.0
- Mounting: Through Hole, Right Angle
- Contact Count: 4 Positions
- Current Rating: 1A per Contact
- Mating Cycles: 1500 Cycles
- Dimensions: (Refer to datasheet for precise footprint)
Applications
The component is engineered for deployment in systems requiring high reliability and performance under specific operating conditions. It provides functional stability across the stated design envelope.
- Data acquisition interfaces in industrial automation equipment
- Peripheral connectivity in embedded computing platforms
- Power delivery and charging ports in consumer electronics
- Signal coupling in test and measurement instrumentation
