20021221-00020C4LF – FCI
Header, 20-Position, 0.050″ (1.27mm) Pitch, Surface Mount Connector
Stock Quantity: 21
Selling Unit: Each
| Quantity | Price (ex VAT) |
|---|---|
| 1+ | 1.21 |
| 10+ | |
| 50+ | |
| 100+ |
21 in stock
Contact us for volume pricing
- Same day shipping if ordered before 14.00 GMT
- 6 month warranty on all stock items
- All stock held and shipped from our UK warehouse
- Worldwide shipping available, contact us for a quotation
- We can ship on your DHL or UPS account if required
- Any import duties or taxes are the responsibility of the receiver
Overview
The FCI 20021221-00020C4LF is a high-density connector designed for critical signal and data transmission in space-constrained applications. Its 1.27mm fine pitch facilitates significant board real estate savings, a crucial consideration in modern compact electronic systems. While the shrouded housing enhances mating reliability, designers must carefully manage the increased susceptibility to flux contamination during assembly due to the reduced spacing, necessitating robust cleaning protocols to maintain long-term signal integrity.
Key Features
- 1.27mm contact pitch for high-density interconnects
- Available in 4 to 100 positions for design flexibility
- Shrouded housing for robust mechanical mating
- Multiple plating options: 0.76µm Gold, 0.25µm Gold, and Gold Flash
- Surface Mount (SMT) and Through-Hole (TH) termination styles
- Tape and reel packaging for automated assembly
Applications
The component is engineered for deployment in systems requiring high reliability and performance under specific operating conditions. It provides functional stability across the stated design envelope.
- High-speed digital interface coupling in compact consumer electronics
- Board-to-board interconnects in portable instrumentation
- Signal routing in medical device internal assemblies
- Data communication links within embedded systems
