1812GC272KAT1A – AVX
2700 pF, 2 kV Ceramic Capacitor, X7R Dielectric, 1812 Package
Stock Quantity: 625
Selling Unit: Each
| Quantity | Price (ex VAT) |
|---|---|
| 1+ | 0.83 |
| 10+ | |
| 50+ | |
| 100+ |
625 in stock
Contact us for volume pricing
- Same day shipping if ordered before 14.00 GMT
- 6 month warranty on all stock items
- All stock held and shipped from our UK warehouse
- Worldwide shipping available, contact us for a quotation
- We can ship on your DHL or UPS account if required
- Any import duties or taxes are the responsibility of the receiver
Overview
The KYOCERA AVX 1812GC272KAT1A is a high-voltage ceramic capacitor designed for robust energy storage and filtering applications. Its primary function is to provide stable capacitance under demanding electrical stress, particularly at 2000V. A critical design consideration when utilizing X7R dielectrics in such high-voltage applications is the potential for capacitance drift with applied DC bias, a phenomenon that must be accounted for in circuit design to ensure predictable performance, especially in sensitive signal paths.
Key Features
- Capacitance: 2700 pF
- Tolerance: ±10%
- Voltage Rating: 2000V (2kV)
- Dielectric: X7R
- Operating Temperature: -55°C to 125°C
- Package: 1812 (4.60mm x 3.20mm x 1.80mm)
Applications
The component is engineered for deployment in systems requiring high reliability and performance under specific operating conditions. It provides functional stability across the stated design envelope.
- High-voltage DC blocking in power supply output stages
- Transient voltage suppression in automotive electronics
- Energy discharge circuits for pulsed power systems
- Decoupling for high-power switching regulators
