170032-1 – TE CONNECTIVITY
FASTON .250 Crimp Receptacle; 6.35×0.8mm, 20-14AWG (0.5-2.27mm²).
Stock Quantity: 17875
Selling Unit: Each
| Quantity | Price (ex VAT) |
|---|---|
| 1+ | 0.13 |
| 10+ | |
| 50+ | |
| 100+ |
17875 in stock
Contact us for volume pricing
- Same day shipping if ordered before 14.00 GMT
- 6 month warranty on all stock items
- All stock held and shipped from our UK warehouse
- Worldwide shipping available, contact us for a quotation
- We can ship on your DHL or UPS account if required
- Any import duties or taxes are the responsibility of the receiver
Overview
The TE Connectivity 170032-1 is a non-insulated, female quick connect terminal designed for robust electrical connections in demanding environments, specifically accommodating wire gauges from 14 to 20 AWG. Its critical operational characteristic lies in its reliable crimp termination, ensuring low contact resistance and mechanical integrity under vibration. A key design consideration for this component is the trade-off between its compact 0.250″ (6.35mm) tab width and the required crimp force for optimal conductor engagement; insufficient crimp pressure can lead to intermittent connections, particularly in high-current applications where thermal cycling is prevalent.
Key Features
- Tab Width: 0.250″ (6.35mm)
- Wire Gauge Compatibility: 14-20 AWG
- Termination Method: Crimp
- Overall Length: 0.756″ (19.20mm)
- Contact Material: Brass
- Insulation Diameter Range: 0.085″ ~ 0.135″ (2.16mm ~ 3.43mm)
Applications
The component is engineered for deployment in systems requiring high reliability and performance under specific operating conditions. It provides functional stability across the stated design envelope.
- High-vibration automotive wiring harnesses
- Industrial control panel power distribution
- Consumer appliance internal power interconnections
- Test equipment signal routing and grounding
