16SVP180M – SANYO
180 µF, 16 V Aluminum Polymer Capacitor, 20% Tolerance, SMD
Stock Quantity: 143
Selling Unit: Each
| Quantity | Price (ex VAT) |
|---|---|
| 1+ | 0.94 |
| 10+ | |
| 50+ | |
| 100+ |
143 in stock
Contact us for volume pricing
- Same day shipping if ordered before 14.00 GMT
- 6 month warranty on all stock items
- All stock held and shipped from our UK warehouse
- Worldwide shipping available, contact us for a quotation
- We can ship on your DHL or UPS account if required
- Any import duties or taxes are the responsibility of the receiver
Overview
The Panasonic 16SVP180M is a high-performance 180 µF, 16V aluminum polymer capacitor designed for demanding applications requiring stable filtering and energy storage. Its exceptionally low Equivalent Series Resistance (ESR) of 20mΩ at 100kHz is critical for managing high ripple currents, a common challenge in power supply designs. However, designers must carefully consider the trade-off between this low ESR and the component’s temperature rating; while it operates at 105°C for 2000 hours, aggressive thermal management is essential to prevent premature degradation and ensure long-term reliability in high-density PCBs.
Key Features
- Capacitance: 180 µF
- Voltage Rating: 16 V
- ESR: 20 mΩ (at 100 kHz)
- Ripple Current: 3.64 A (at 100 kHz)
- Operating Temperature: -55°C to 105°C
- Dimensions: 8.00mm Diameter x 12.00mm Height
Applications
The component is engineered for deployment in systems requiring high reliability and performance under specific operating conditions. It provides functional stability across the stated design envelope.
- High-frequency decoupling for digital processors and ASICs
- Power sequencing for high-speed DDR memory modules
- Output filtering in compact DC-DC converters
- Smoothing in automotive infotainment systems
