12FLZ-SM2-TB – JST

Part Number:

12FLZ-SM2-TB

Manufacturer:

JST

Date Code:

06+

RoHS:

RoHS Compliant

MSL:

COO:

Description:

12-Position FFC/FPC Connector, 0.50mm, Top Contact, Right Angle, Surface Mount

Datasheet:

Spotted a problem with product information? – let us know

ORDER NOW

Stock Quantity: 0

GET QUOTE

Contact us for volume pricing

Same day shipping if ordered before 14.00 GMT
6 month warranty on all stock items
All stock held and shipped from our UK warehouse
Worldwide shipping available, contact us for a quotation
We can ship on your DHL or UPS account if required
Any import duties or taxes are the responsibility of the receiver

Product Details:

Overview

The 12FLZ-SM2-TB is a 12-position Flexible Flat Cable (FFC) and Flexible Printed Circuit (FPC) connector manufactured by JST. This connector features a 0.50mm pitch, top contact configuration, and a right-angle orientation for surface mount assembly onto printed circuit boards. It provides a secure and reliable connection for signal transmission in compact electronic devices.

Key Features

12 Positions
0.50mm Pitch
Top Contact
Right Angle Orientation
Surface Mount Termination

Applications

This FFC/FPC connector is typically used in applications requiring high-density interconnects and low-profile designs. Its compact size and reliable connection make it suitable for various electronic assemblies.

LCD Displays
Mobile Devices
Digital Cameras
Portable Electronics
